CO2 recovery Plant for craft breweries, complete solution
CO2 recovery plant for small scale brewing

CO2 Recovery Plant

Small efforts have a big impact!

CO2 Recovery Plant by Hypro enables you to become self-reliant and eliminates the need of buying the CO2 from the market. The carbon dioxide sold by the local sources may come after the recovery of CO2 from flue gas generated during the burning of oil/diesel or it may come from a biogas plant or a distillery or a chemical plant.
To use this carbon dioxide a craft brewery needs a CO2 cylinder station, distribution network, and manpower to handle the gas. To know if the gas is food grade or not, complex analytics are needed. Hypro offers you the HyCrCTM Plants, simplifying the entire CO2 Recovery process. With this advanced CO2 Recovery Plant, you can be sure that you’re getting only pure CO2, with the source being the fermentation of your own craft beers.

Empower your brewery with

Sustainable CO2 Recovery Process

and reduce carbon footprint!

01

Product Description

This CO2 Recovery Plant is well-engineered to collect CO2 in vapor form, convert it into liquid so as to increase the storage capacity in minimum possible floor area, and evaporate the liquid to vapor form to be used back in the brewery and that too by recovering energy. An operator is provided with a panel that serves as an interface between the plant and the human being. The operation panel is simplified for use by the brewer or assistants and eliminates the need for a dedicated operator.

02

Functionality

For seamless CO2 recovery process with this plant  Breweries need to connect all of the raw CO2 generated, electrical power, water, glycol, compressed air to the inlet of plant and HyCrCTM will deliver pure CO2 > 99.998 % v/v at the outlet of recovery plant and at 7 Bar g pressure in vapor form.

HyCrC in Drinktec

03

Features

  • Produces 15 kg/hr and above Liquid CO2
  • Produces CO2 with purity in excess of
    99.998% v/v
  • 100% food-grade CO2 from a known source
  • High-grade surface finishes and weld seams
  • Complete contact parts built in SS 304
  • Optimal Pressure: 16-18 Bar g for efficiency
  • CO2 Low-Pressure Purification (Foam washing and removal of water-soluble impurities)
  • CO2 High-Pressure Purification for moisture and odor removal
  • Glycol-based liquid CO2 Evaporation with energy recovery feature

04

Advantages

  • Compact Design
  • User-friendly & hassle-free operation
  • Minimized Flashing Losses for maximum CO2 recovery
  • Design versatility, allowing all the functions to be combined in fewer vessels for the economy, or separated into several vessels for increased capacity
  • Eliminates handling of CO2 cylinders
  • PLC operated fully automatic with remote access
  • Reduced CO2 Consumption: 1.5-2 kg/hl

05

Components

  • CO2 Buffer Balloon
  • CO2 Compression
  • CO2 Condensation using a refrigerant with low GWP
  • CO2 Distillation / Rectification
  • Liquid CO2 Storage
  • Optional add-on HySAAA module for plant and maintenance management with MIS reporting

We would love to see you on social media!

Compare with similar products



CO2 recovery system with utmost purity

MEE CO2 Recovery System

  • 150 kg/hr and above Liquid CO2 produced
  • Recovers CO2 from Breweries, Distilleries, and Wineries
  • Ideal for large scale production
CO2 Recovery Plant at Greenlyte Carbon Technologies 15 Kgh

Hypro HyCrCTM Plant

  • 15 kg/hr and above Liquid CO2 produced
  • Recovers CO2 from Micro/Pub/Craft Breweries
  • Ideal for small scale production
Supercritical CO2 Recovery Plant by Hypro installed at YCH

Supercritical CO2 Recovery Plant

  • Up to 700 kg/hr CO2 produced
  • Ideal for Supercritical Hops Extraction
  • Ideal for large scale production

Frequently Asked Questions.

CO2 is required for the carbonation of the beer which is an essential step in beer brewing as it forms the beer bubbles.

An ideal way to achieve pure CO2 is to utilize carbon dioxide from your own source. CO2 is produced during fermentation in beer making.  Why not recover the CO2 from your own brewery which guarantees perfect quality control – a benefit that no other source can offer.

Continuously changing climate conditions have a potential demand to alter traditional brewing practices that have been passed down to generations. CO2 Recovery is a necessary practice that should be implemented by not only Industrial breweries but also Microbreweries in order to reduce carbon emissions and thereby save mother earth.

The recommended CO2 pressure range is between 7 to 38 PSI depending upon the style of the beer such as Ales, Lagers, Pilsners, and Stouts, etc. An inaccurate pressure may result in under or over carbonation. This may have adverse effects like flat or overly foamy beer.

Save earth

Often Combined with

If you are planning to set up a Craft Brewery or already have one, Hypro offers a complete solution that is totally customized as per your needs. Hypro HyCrCTM is the small scale CO2 Recovery Plant specifically designed for craft breweries. We have successfully commissioned Craft Brewery Plants along with Hypro HyCrCTM Plant in order to make the breweries self-reliant on CO2 supply, all the while contributing to the greener earth.
